| WLL | 1.000,00 kg |
| Max. temperatur | 80,00 °C |
| Min. temperatur | -10,00 °C |
| Driftspänning | 400,00 V |
| Lyftriktning | horisontell |
| Typ av last | Series parts, cuttings |
| Standard | EN13155, MRL 2006/42EWG |
| Max. lastväxling | 16 000 lastcykler |
| Produktbeskrivning | Elektrisk permanentmagnet |
| Tillverkare | Flaig TE Magnetsysteme |
| Typbeteckning | FXE-1000/80 |
| eClass 6.2 | 36123405 |
| eClass 5 | 36129090 |
| eClass 7.1 | 36123405 |
| UNSPSC V7 | 24101658 |
| eClass 8.0 | 36123405 |
| UNSPSC V13.5 | 24101658 |
| eClass 5.1.1 | 36129205 |
| eClass 5.1 | 36129205 |
| eClass 9.0 | 36123405 |
| eClass 10.0.1 | 36123405 |
| eClass 10.1 | 36123405 |
| UNSPSC V20.0601 | 24101658 |
| eClass 5.1.4 | 36129205 |
| UNSPSC V13.5_S | 241016 |
Equipped with pole type 80 and a maximum load capacity of 1000 kg, which is reached with material thicknesses from 25 mm, these
easy to guide and operate devices are recommended for lifting heavy plates,
plasma and flame cut parts, tools and blanks with medium air gap.
