Product description
The Permanent Lifting Magnet MaxX TG 300kg for 10mm material is a specialised magnetic lifting solution developed for the safe and controlled handling of thin ferromagnetic plates and thin-walled pipes. It is ideal for use in sheet metal processing, fabrication, laser cutting, warehousing and industrial material handling applications where precise lifting of thin materials is essential.
Designed for flat materials up to 10mm thickness, this lifting magnet provides a rated working load limit of 300kg. The break-away force is at least three times the stated working load limit, ensuring a high level of operational safety during lifting and positioning. When handling round material, the prismatic bottom enables stable positioning, with a working load limit of at least 50% of the rated capacity for flat material.
The MaxX TG lifting magnet features an easy-moving operating lever with an integrated safety lock to prevent accidental release during use. Its compact and sturdy design supports reliable performance and long service life, even in demanding industrial environments. A large, bolted lifting eye is fitted and sized according to the nominal load capacity, ensuring secure attachment to crane hooks and lifting equipment.
Each Permanent Lifting Magnet MaxX TG is individually tested prior to delivery and supplied with a test certificate and operating instructions, supporting compliance with inspection requirements and site safety procedures. As a permanent magnet system, it operates without electricity, reducing operating costs and eliminating reliance on external power sources.
The MaxX TG 300kg permanent lifting magnet provides a dependable and efficient solution for lifting thin steel plates and components where safety, precision and durability are essential in professional industrial lifting applications.
